G3151DP 4-20mA smart differential pressure transmitter price

Electrical technical parameters
Power supply	17.5 - 45VDC	Output signal	4 - 20mA DC / HART
HART communication load	250 - 1500 Ohm	Insulation strength	100V AC
Refresh time	0.25 Sec.	Start-up time	5 Sec.

Perfermance techanical parameters
Accuracy	±0.075%FS	Operating temp.	-40 - 85℃
Relative humidity	5% - 98%	Operating temp. (LCD display)	-20 - 70℃
Medium temp. (Max.)	-40 - 104℃	Stability	±0.1%
Temp. effect	≤0.45% / 55℃

Mechanical techanical parameters
Isolation diaphragm	316LSST	Flow connection	1/4 - 18NPT
Bleed valve	316LSST	Joint (optional)	1/2 - 14NPT
Joint	316LSST	Electrical connection	1/2 - 14NPT
O ring gasket	Nitrile rubber	Weight	3.9kg
Electric box	Aluminium alloy	Ingress protection	IP65
Joint bolt	Galvanized carbon steel

G3151DP	Differential pressure transmitter
	No.	Pressure range
	3	0-1.25 ~ 7. 64 KPa
	4	0-6. 22 ~ 37.39 KPa
	5	0-31. 10 ~ 186.40 KPa
	6	0-117.21 ~ 689.48 KPa
	7	0-0. 34 ~ 2. 07 MPa
	8	0-1. 17 ~ 6. 89 MPa
	9	0-3.45 ~ 20.68 MPa				without fluorine and isolation membrane
	0	0-6. 89 ~ 41.37 MPa
		No.	Output
		B	4-20mA with HART protocol
			No.	Material structure
				Pressure chamber				Bleed valve	Isolation diaphragm	Filling liquid
			2 2	316LSST				316LSST	316LSST	Silicone oil
			2 3	316LSST				316LSST	Hastelloy C-276
			2 4	316LSST				316LSST	Monel alloy
			2 5	316LSST				316LSST	Tantalum
			3 3	Hastelloy C				Hastelloy C	Hastelloy C-276
			3 5	Hastelloy C				Hastelloy C	Tantalum
			4 4	Monel alloy				Monel alloy	Monel alloy
			7 3	316LSST				Hastelloy C	Hastelloy C - 276
			2 A	316LSST				316LSST	316LSST	Fluorine oil
			2 B	316LSST				316LSST	Hastelloy C - 276
			3 B	Hastelloy C				Hastelloy C	Hastelloy C - 276
			2 D	316LSST				316LSST	Tantalum
			3 D	Hastelloy C				Hastelloy C	Tantalum
			7 B	316LSST				Hastelloy C	Hastelloy C - 276
					No.		Item optional
					T		1/2NPT (Female) 316 L SST
					O		1/4NPT (Female) 316 L SST
					No.		Item optional
					M7		Linear indicator 0~100
					Bl		Pipe mounting curved bracket (D=51mm)
					B2		Plate mounting bracket
