Diameter

DN32~DN6000

Pipe Material

Steel, Stainless steel, Cast iron, Copper, Cement pipe,

PVC, Aluminum, Glass steel product, liner is allowed

Temperature(℃)

4~160

Difference range (K)

3~70

Min pairing

temperature error(℃)

±0.1

Max allowable

working pressure(MPa)

1.6(Outside of scope, please consult customer service staff before ordering)

Accuracy

Class 2

Traffic transducer

protection level

IP67

Temperature transducer protection level

IP68

Power supply

8 built-in Ni-MH batteries 1.2V(for over 20 hours of operation).90V-260VAC adapter

Power consumption

1.5W

Working condition

Host:-20~60℃;Traffic transducer :-30~160℃

Host:85%RH; transducer protection level:IP67

Communication

RS485

Local display

2×10 character LCD with backlight,2 x 10 character western liquid crystal display,support the language of Chinese, English and Italy

Display resolution

Accumulated heat:0.001kGJ;Thermal power:0.0001GJ/h;Temp.:0.001℃;Differential temp.:0.0001℃

Max reading

Net cumulative flow:9999999~9999999m³

Net cumulative heat:0~9999999GJ

Storage temperature(℃)

-20~+60

Data storage

Thermal printer,external SD card (2G of capacity)

Installation location

Water supply line, backwater line
